Open Mill Machine adopts special heated mold, roll surface temperature uniformity, never take off a layer, sample thickness can be mixed.
| Brand: | OLLITAL |
| Model: | ZS-401B-120 |
| Warranty: | 1 year |
| Delivery time: | 7-15 days |
* All our products can be customized according to drawings and requirements.Contact our engineers now to find out the most suitable and cost-effective solution !
Two roll open mixing mill is used for rubber&plastic raw material mixing and modification, just like the PVC EVA NBR SBR etc.The specific proposal would be based on the materials characteristic, production capacity.
Technical Parameter
| Model | ZS-401A-120 | ZS-401B-120 | ZS-401C-120 |
| Size of roll(mm) | 120x350 or customized | ||
| Heating mode | Electrical heating or oil heating | ||
| Cooling mode | Tap water cooling/oil cooling (optional) | ||
| Roller speed | Constant speed | Single speed regulator | Double frequency modulation |
| Motor power(kw) | 0.75X1®or customized | 0.75X1® or customized | 0.75X2or customized |
| Volume(mm) | 1000X550X1200 | 1000X550X1200 | 1000X550X1200 |
| Weight(kg) | 350 | 370 | 400 |
| Power supply | 3ph, AC380V | ||
| Special models can be designed according to customers requirements | |||
* All our products can be customized according to drawings and requirements. Contact our engineers now to find out the most suitable and cost-effective solution!
