Vulcanizer uses a flat mold to vulcanize, which is suitable for rubber products of various shapes, with high production efficiency and stable product quality.
Lead Time:1-3 days
Model Number: OLT-406
Minimum Order Quantity: 1
Operation method: PLC
Mixing method: Touch Screen
Warranty: 1 year
* All our products can be customized according to drawings and requirements.Contact our engineers now to find out the most suitable and cost-effective solution !
The material is placed in the casting mold and clamped between the electric-heating flat plates to apply pressure and temperature,make the material shaping,testing and serving as the basis for the ingredient of mass production.
| Model | OLT-406A | OLT-406B | OLT-406C | OLT-407 |
| Control mode | Manual Type | Electrice Type | PLC Control | Vacuum |
| Pressure(T) | 10/20/30/50/75/100 tons or customized | |||
| Temperature range | Room temperature -300 ℃ | |||
| Size of working board(mm) | 300*300mm or customized | |||
| Volume(mm) | 750*400*800 | 1000*600*1600 | 1000*600*1600 | 1100*600*1700 |
| Weight(kg) | 210 | 750 | 750 | 800 |
| Power supply | 3∮,AC380 | |||
| Special models can be designed according to customers' requirements | ||||
* All our products can be customized according to drawings and requirements. Contact our engineers now to find out the most suitable and cost-effective solution!
1) Equipped with a high performance hydraulic system with automatic pressure compensation function;
2) High precision and high wear-resistant guide posts to support strong load force and stable lifting;
3) Electric heating and PID temperature control to fast heat and precisely control the temperature;
4) Adjustable molding time;
5) Automatically increase and release the pressure when reaching the set time.
6) PLC Control system
