The machine adopts frequency converter to control traction, friction single roll and lifting, and is suitable for blowing HDPE/LDPE industrial.
| Brand: | OLLITAL |
| Model: | OLT-BF600 |
| Warranty: | 1 year |
| Power | 3∮, AC380V |
| Delivery time: | 7-15 days |
* All our products can be customized according to drawings and requirements.Contact our engineers now to find out the most suitable and cost-effective solution !
It is used for blowing various plastic film of low density polyethylene (LDPE),high density polyethylene (HDPE)and linear low density polyethylene(LLDPE)etc., Which are Widely used for food, textiles, and daily necessities such as the packing industry and export packing and industrial packing. And after formula it can produce pearly luster membrane and degradable film.
| Model | OLT-BF600 | OLT-BF800 | OLT-BF1000 |
| Die of screw | Φ40mm*2 | Φ45mm*2 | Φ50mm*2 |
| Ratio of screw | 30:1 | ||
| Speed of screw | 10-140rmp | ||
| Max output | 70-80kg/h | 80-110kg/h | 90-110kg/h |
| Power of main motor | 11kw*2 | 15kw*2 | 18.5kw*2 |
| Die model | Φ50mm | Φ80mm | Φ220mm |
| Thicknedd of film | 0.008-0.12mm | ||
| Max folding width of film | 200-600mm | 200-800mm | 500-1000mm |
| Machine weight | 3.0T | 4.0T | 6.0T |
| Machine dimension | 5800*2400*4800mm | 5800*2600*5200mm | 6000*2800*5200mm |
