Fully automatic vulcanizing machine is used for silicone rubber tire production, high temperature can be customized,
| Brand: | OLLITAL |
| Model: | OLT-50T |
| Heating | Electric heating |
| Number of hot plates | 2 |
| Maximum use system pressure | 16Mpa |
| Warranty: | 1 year |
| Delivery time: | 7-15 days |
* All our products can be customized according to drawings and requirements.Contact our engineers now to find out the most suitable and cost-effective solution !
This professional belt vulcanizer/tire vulcanizer/plate vulcanizer is used to press various types of rubber molded products and non-molded products. It is the main equipment and can also be used to press various types of thermosetting plastics and foam rubber products. The independent mechanism and electrical system use centralized control buttons. The working pressure and heating temperature can be adjusted within a certain range. There are manual and semi-automatic models
| Model | 50T | 63t |
| Nominal clamping force(KN) | 500 | 630 |
| Hot plate specifications(MM) | 400*400 | 500*500 |
| Working layer | 2 | 2 |
| Maximum fluid pressure(Mpa) | 16 | 20 |
| Plunger diameter(MM) | 200 | 200 |
| Plunger stroke(MM) | 250 | 250 |
| Heating | Electric heating, steam heating, oil heating | |
| Motor Power(KW) | 2.6 | 2.6 |
* All our products can be customized according to drawings and requirements. Contact our engineers now to find out the most suitable and cost-effective solution!
Professional Belt Curing Press/Tire Curing Press/Flat Vulcanizing Machine
• Adopts digital time relay for automatic mould clamping, timing alarm function. It can auto-stop, auto-exhaust, automatic timing, automatic fill pressure and automatic opening function, which can effectively pretect the fulfur and the suppression of products quality.
•Electric heating time using digital temperature controller with proportional control box display ammeter
hot plate temperature and the working conditions of the heating element. With temperature control and high precision, intuitive display, easy adjustment. Steam heating with stainless steel metal hoses, reliable performance and durability.
•The hydraulic system uses a combination of double linkage pumps, both to improve efficiency and save energy. Low demand for oil, less failure, less noise.
•With automatic bleed function, and deflation and deflation time frequency adjustable
